Kuka 151679

KR 5 arc-C

MPN: 151679
Category: Low payload class (5 to 20 kg)

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via

What is the Kuka 151679?

Kuka KR 5 arc-C, manufacturer part number 151679. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Rated payload	5 kg
Maximum reach	1412 mm
Mounting position	Ceiling
Pose repeatability (ISO 9283)	0.04 mm
Number of axes	6
Ambient temperature during operation	10 °C to 55 °C (283 K to 328 K)
Ambient temperature during stor./transp.	-40 °C to 60 °C (233 K to 333 K)
Protection rating (IEC 60529)	IP54
Prot. rating, in-line wrist (IEC 60529)	IP65
A1	154 °/s
A2	154 °/s
A3	228 °/s
A4	343 °/s
A5	384 °/s
A6	721 °/s

151679: frequently asked questions

When can 151679 be shipped?

151679 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 151679 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 151679 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 151679, subject to availability and destination.
