Keyence SR-SW10

Ethernet switch. . Series: Scan Tunnel System. Series code: ST series

MPN: SR-SW10
Category: Scan Tunnel System

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via

What is the Keyence SR-SW10?

Ethernet switch. SR-SW10. Series: Scan Tunnel System. Series code: ST series

Specifications

Model Name	Ethernet switch
Model Code	SR-SW10
Series Title	Scan Tunnel System
Series Code	ST series
Data Sheet URL	https://www.keyence.com/download/download/confirmation/?dlSeriesId=WS_157175&dlModelId=PM_193SW10&dlSiteId=1&dlLanguageId=en-US&dlLangType=en-US
CAD URL	https://www.keyence.com/products/barcode/barcode-readers/st/downloads/?mode=cd&modelId=PM_193SW10
Manuals URL	https://www.keyence.com/products/barcode/barcode-readers/st/downloads/?mode=ma&modelId=PM_193SW10
Model	SR-SW10
Type	Ethernet hub
I/O Specifications - Ethernet communication	4
I/O Specifications	2
Power supply - Connector type	M12, 5-pin, male, L-code
Power supply - Ratings	24 V DC + 25%/-20%
Power supply	10.8 A, 207.4 W (at 19.2 V)/7.6 A, 182.4 W (at 24 V)
Environmental resistance - IP enclosure rating	IP67 (IEC 60529)
Environmental resistance - Ambient temperature	0 to +50°C 32 to +122°F
Environmental resistance - Relative humidity	Max. 85% RH (no condensation)
Environmental resistance - Vibration resistance	10 to 500 Hz power spectral density: 0.05 G2/Hz0.5 hours in X/Y/Z directions (IEC 60068-2-64)
Environmental resistance - Shock resistance	50 G in 6 directions, 3 times each (IEC 60068-2-27)
Material	Housing material: Aluminum die-cast
External dimensions L × W × H (mm inch)	176.4 × 80.4 × 43.4 6.94" × 3.17" × 1.71" (excluding connector protrusion)
Certifications	CSA, FCC, ICES, KC, CE, UKCA
Weight	750 g 26.45 oz (830 g 29.27 oz: including mounting hardware)

SR-SW10: frequently asked questions

When can SR-SW10 be shipped?

SR-SW10 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up SR-SW10 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for SR-SW10 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for SR-SW10, subject to availability and destination.
