Keyence OP-88296
Loose wires/M12 adapter. . Series: Compact Laser Sensor. Series code: LR-X series
- MPN
- OP-88296
- Category
- Compact Laser Sensor
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
What is the Keyence OP-88296?
Loose wires/M12 adapter. OP-88296. Series: Compact Laser Sensor. Series code: LR-X series
Specifications
Specifications
| Model Name | Loose wires/M12 adapter |
| Model Code | OP-88296 |
| Series Title | Compact Laser Sensor |
| Series Code | LR-X series |
| Data Sheet URL | https://www.keyence.com/download/download/confirmation/?dlSeriesId=WS_SR57360&dlModelId=PM_9688296&dlSiteId=1&dlLanguageId=en-US&dlLangType=en-US |
| CAD URL | https://www.keyence.com/products/sensor/photoelectric/lr-x/downloads/?mode=cd&modelId=PM_9688296 |
| Manuals URL | https://www.keyence.com/products/sensor/photoelectric/lr-x/downloads/?mode=ma&modelId=PM_9688296 |
| Model | OP-88296 |
| Type | Loose wires/M12 adapter |
| Applicable product | FD-XA1/XA5 cables, or cables with cross sectional area 0.14 to 0.34 mm2and outer diameter ø 3.5 to 6 mm 0.14 " to 0.24 " |
| Frequency of connections between conductors of the same cross section | 10 |
| Insertion/withdrawal cycles | More than 100 times |
| Wire diameter including insulation | ø 0.7 to 1.6 mm 0.028 " to 0.06 " |
| enclosure rating | IP65/67 |
| Ambient temperature | -25 °C to +80 °C -13 to 176 °F |
| Note | A connector that converts loose wires to a M12 4-pin connector. Useful for connecting to IO-Link compatible master units. |
| Weight | Approx. 12 g 0.42 oz |
OP-88296: frequently asked questions
When can OP-88296 be shipped?
OP-88296 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up OP-88296 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for OP-88296 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for OP-88296, subject to availability and destination.
