Keyence IG-028

Sensor Head. . Series: Multi-Purpose CCD Laser Micrometer. Series code: IG series

MPN: IG-028
Category: Multi-Purpose CCD Laser Micrometer

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via

What is the Keyence IG-028?

Sensor Head. IG-028. Series: Multi-Purpose CCD Laser Micrometer. Series code: IG series

Specifications

Model Name	Sensor Head
Model Code	IG-028
Series Title	Multi-Purpose CCD Laser Micrometer
Series Code	IG series
Data Sheet URL	https://www.keyence.com/download/download/confirmation/?dlSeriesId=WS_SR47840&dlModelId=PM_236028&dlSiteId=1&dlLanguageId=en-US&dlLangType=en-US
CAD URL	https://www.keyence.com/products/sensor/positioning/ig/downloads/?mode=cd&modelId=PM_236028
Manuals URL	https://www.keyence.com/products/sensor/positioning/ig/downloads/?mode=ma&modelId=PM_236028
Model	IG-028
Operation principle	CCD method
Light source - Wavelength	660 nm (Visible light semiconductor laser)
Light source - FDA	Class 1*1
Light source - IEC/JIS	Class 1
Mounting distance	0 to 1500 mm 59.06"
Measurement range	28 mm 1.10"
Sampling cycle	980 µs (When the number of times for averaging is set to [hsp]: 490 µs)
Minimum detectable object - High sensitivity mode	ø0.1 mm ø0.003" (Setting distance: 100 mm 3.94")*2
Minimum detectable object - Standard mode	ø0.2 mm ø0.007" (Setting distance: 50 mm 1.97" or less),ø0.5 mm ø0.02" (Setting distance: 500 mm 19.68")*2
Repeatability	5 µm 0.20 Mil (Setting distance: 100 mm 3.94")10 µm 0.39 Mil (Setting distance: 500 mm 19.68")80 µm 3.15 Mil (Setting distance: 1,000 mm 39.37")140 µm 5.51 Mil (Setting distance: 1,500 mm 59.06")*3
Linearity	±0.1 % of F.S. (±28 µm ±1.10 Mil)*4
Temperature characteristics	±0.01 % of F.S./°C (±3 µm ±0.12 Mil/°C)*5
Operation indicator - Transmitter	Optical axis alignment indicator: Green LED, Power indicator: Green LED
Operation indicator - Receiver	Optical axis alignment indicator: Green LED, Position monitor: Dual bar LED (Red, Green)
Environmental resistance - Enclosure rating	IP67
Environmental resistance - Ambient light	Incandescent lamp: 5,000 lux, Sunlight: 5,000 lux*6
Environmental resistance - Ambient temperature	-10 to +45 °C 14 to 113 °F (No freezing)
Environmental resistance - Relative humidity	35 to 85 % RH (No condensation)
Environmental resistance - Vibration resistance	10 to 55 Hz, Double amplitude 1.5 mm 0.06", 2 hours in each of the X, Y, and Z axis
Material - Case	Zinc die-cast (Lower case), PBT (Upper case), Polyarylate (PAR) (Display part), SUS304 (Metallic part)
Material - Lens cover	Glass
Material - Cable	PVC
Accessories	Transmitter × 1, Receiver × 1, Sensor head cables (2 m 6.56') × 2
Weight	Approx. 500 g (including supplied items)
