Honeywell – VMU150A1052 Venturi 150KW With Insert

MPN: VMU150A1052 · Brand: Honeywell

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Honeywell Combustion & Burner Controls
Lifecycle	Active
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

When can VMU150A1052 be shipped?

VMU150A1052 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up VMU150A1052 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for VMU150A1052 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for VMU150A1052, subject to availability and destination.

Part of Honeywell's V47/V87/VR/VMU Series range. V4730C; V4734C; V8730C Gas/Air Servo Regulated Gas Valves & VMU Mixing Units

Body Pattern: Straight flange Valve

Opening Time: Dead time maximum: 1 s; First valve – < 1 s

Materials: Body: Aluminum alloy, die-cast Frequency: 50 Hz; 60 Hz Ambient Temperature Range: 5°F to 140°F (-15°C to +60°C)

Approvals, CSA: File: Certificate No: 158158-1227192

Approvals, Others: Gas Appliance Directive: 90.396/EEC, PIN: 0063AT1198, Low Voltage Directive: 73/23/EEC, Electro Magnetic Compatibility Directive: 89/336/EEC

Maximum Safe Operating Pressure (psi): 0.5 psi (CSA approved), 1.45 psi for 120V)

Maximum Operating Pressure (mbar): 35 mbar (CSA approved)

Comments: The minimum load for which the system can be used is 14-17% of the reference load, which equals a minimum pressure differential of 0.2 in. wc (50 Pa) of the 1:1 venturi/servo regulator gas control

Coil Insulation Solenoid Valves: Class H insulation system VMU Mixing UnitsThe venturi mixing unit (VMU), combined with the V4730C/ V8730C gas valves and specific direct current (dc) fan, has been developed for modulating premix appliances like gas burners and gas boilers.

Has a wide modulation band (14 to 100% of the boiler load).

Flexible mounting positions of gas control to venturi manifold and venturi manifold to fan.

Two stainless steel sensing tubes are provided for use with or without manual safety shutoff valve.

Materials: Housing: Aluminum, Venturi: Statically dissipative statcon PF, Seals: Rubber (NBR)

Ambient Temperature Range: 32°F to 212°F (0°C to 100°C)

Approvals, CSA: File: Certificate No: 158158-1227192

Pipe Connection: Four M5 screws and a rubber O-ring are provided with the venturi to assemble it to the V4730C/V8730C gas valve

The stainless steel tube provided with the venturi has to be connected between the venturi inlet (connection provided) and the gas valve regulator

Longer sensing tube for use with manual safety shutoff valve (KTTBA002). Shorter sensing tube for use without manual safety shutoff valve (KTTBA001).

Honeywell VMU150A1052 — Venturi 150KW With Insert (V47/V87/VR/VMU Series). PartnerPLC sources new, surplus and discontinued Honeywell parts — request a quote for price, condition and lead time.
