Honeywell TTM1K-3-D12-GD-4
A/TTM1K Series Temperature Transmitter
- MPN
- TTM1K-3-D12-GD-4
Discontinued by Honeywell — we can still source the original TTM1K-3-D12-GD-4 (new, used or refurbished, subject to availability). Request a quote below.
Request a Quote
- 1We check stock, condition and lead time
- 2You get a written quote by email
- 3Approve it and we ship — in-stock parts within 1 business day
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- 100% positive eBay feedback
- Ships via
What is the Honeywell TTM1K-3-D12-GD-4?
ACI A/TTM1K series temperature transmitters are a cost effective solution for all temperature measurement needs. These temperature transmitters are accurate, durable, and reliable. In addition, numerous mounting configurations are offered. ATTM1K series temperature transmitters are designed for use with a 1K ohm platinum RTD. The transmitters produce a linear 4-20 mA output carried on a two-wire system. Optional output voltage ranges of (+1-5 or +2-10 VDC) are also available.
The transmitters are supplied factory calibrated, and supplied with zero and span potentiometers for field calibration. To enhance overall performance, the A/TTM1K series offers a matched calibration of the sensor and transmitter which improves the measurement accuracy by eliminating the sensor tolerance error. N.I.S.T. certificate is provided on all A/TTM series sensors. Data acquisition, OEM, process control, clean rooms are the applications of temperature transmitters. Temperature transmitters are double encapsulated to provide additional protection against moisture and corrosion. Temperature transmitters are calibrated with high quality equipment to optimize long term performance. Features & Benefits:
Reverse Polarity Protected
Class A RTD included
Custom calibration ranges are availableCertifications:
NIST certificate
Honeywell Alerton TTM1K-3-D12-GD-4 — A/TTM1K series temperature transmitters are a cost effective solution for all of temperature measurement needs, these transmitter’s are double encapsulated to provide additional protection against moisture and corrosion. Discontinued by Honeywell — no longer in the current range. PartnerPLC sources new, surplus and discontinued Honeywell parts — request a quote for price, condition and lead time.
Specifications
Product
| Lifecycle | Discontinued by Honeywell |
| Brand line | Alerton |
Others
| Minimum Operating Ambient Temperature | -40 degree Celsius, -40 degree Fahrenheit |
| Maximum Operating Ambient Temperature | 185 degree Fahrenheit, 85 degree Celsius |
| Brand | Alerton |
| Number of Wiring Terminals | 2 |
| Detector Type | Duct Temperature |
| Product Type | Sensor Degrees Celsius |
Ordering codes
| Part numbers on this product page | TTM1K-3-D12-GD-4, TTM1K-3-D18-GD-4, TTM1K-3-D4-GD-4, TTM1K-3-D8-GD-4 |
No matching specifications
TTM1K-3-D12-GD-4: frequently asked questions
Can I still buy the TTM1K-3-D12-GD-4 now that it is discontinued?
Yes. Honeywell has discontinued the TTM1K-3-D12-GD-4, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time.
When can TTM1K-3-D12-GD-4 be shipped?
TTM1K-3-D12-GD-4 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up TTM1K-3-D12-GD-4 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for TTM1K-3-D12-GD-4 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for TTM1K-3-D12-GD-4, subject to availability and destination.
