Honeywell – TS-5006-XD-10-AB Rigid Copper Averaging Temperature Sensors
Discontinued by Honeywell — we can still source the original TS-5006-XD-10-AB (new, used or refurbished, subject to availability). Request a quote below.
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | Honeywell Building Sensors & Detectors |
| Lifecycle | Discontinued |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
Shipping & availability
Can I still buy the TS-5006-XD-10-AB now that it is discontinued?
Yes. Honeywell has discontinued the TS-5006-XD-10-AB, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time.
When can TS-5006-XD-10-AB be shipped?
TS-5006-XD-10-AB is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up TS-5006-XD-10-AB in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for TS-5006-XD-10-AB and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for TS-5006-XD-10-AB, subject to availability and destination.
The TS-5006-RD and TS-5012-RD Series rigid averaging sensors are both non-polarity and non-position sensitive. These averaging sensors may be used for Monitoring Return Air Temperature, Mixed Air Temperature, Discharge Air Temperature.
The TS-5006-RD and TS-5012-RD Series rigid copper averaging temperature sensors have an output of 3K Ohms at 77F (25C) and 10K Ohms (Type II) at 77F (25C). The rigid averaging temperature sensors have an overall sensor accuracy of ± 0.36F (0.2C) over the range of 32 to 158F (0 to 70C). Each of the rigid copper averaging temperature sensors shall have two 12” (304.8 mm) 26 AWG colored Etched Teflon lead wires enclosed in a single gang galvanized junction box. Each sensor is made of a soft annealed copper tube that is hermetically sealed at both ends. The rigid averaging temperature sensors should be used in environments where the operating temperature is between -22 to 185F (-30 to 85C). Features & Benefits:
Rigid Copper Tubing
Higher Operating Temperature
Fast Response Times
High Accuracy
Durability
2-year Warranty
Honeywell Alerton TS-5006-XD-10-AB — TS-5006-RD and TS-5012-RD Series rigid averaging sensors are both non-polarity and non-position sensitive & These averaging sensors may be used to monitor and control the building temperature in ducts or plenums. Discontinued by Honeywell — no longer in the current range. PartnerPLC sources new, surplus and discontinued Honeywell parts — request a quote for price, condition and lead time.
Specifications
Product
| Lifecycle | Discontinued by Honeywell |
| Brand line | Alerton |
Others
| Minimum Operating Ambient Temperature | -40 degree Celsius, -40 degree Fahrenheit |
| Maximum Operating Ambient Temperature | 150 degree Celsius, 302 degree Fahrenheit |
| Brand | Alerton |
| Product Type | Sensor Degrees Celsius |
Ordering codes
| Part numbers on this product page | TS-5006-XD-10-AB, TS-5012-XD-03-AB, TS-5012-XD-10-AB |
