Honeywell – SCRLA L-Series Wall Strobe

L-Series strobes are rich with features guaranteed to cut installation times with its lower current draw and modern aesthetics. With white and red plastic housings, wall- and ceiling mount options, standard and compact devices, and plain, FIRE-, and FUEGO-printed devices, these strobes can meet virtually any application requirement.

All devices feature a plug-in design with minimal intrusion into the back box, making installations fast and foolproof while virtually eliminating costly and time-consuming ground faults. To further simplify installation, L-Series strobes utilize a universal mounting plate so installers can mount them to a wide array of backboxes. With an onboard shorting spring, installers can test wiring continuity before the device is installed.

Features & Benefits:

Plug-in design with minimal intrusion into the backbox

Tamper-resistant construction

Automatic selection of 12 or 24V operation at 15 and 30 candela

Field-selectable candela settings on wall units: 15, 30, 75, 95, 110, 135, and 185

Universal mounting plate for ceiling units

Mounting plate shorting spring feature checks wiring continuity before device installation

Electrically compatible with legacy SpectrAlert® and SpectrAlert Advance devices

Certifications:

UL Listed: S5512- S4011

ULC Listed

FM Approved

CSFM Approved: 7125-1653:0504- 7135-1653:0503

Honeywell Farenhyt, Gamewell-FCI, NOTIFIER, System Sensor SCRLA — L-Series strobes are rich with features guaranteed to cut installation times with its lower current draw and modern aesthetics. Discontinued by Honeywell — no longer in the current range. PartnerPLC sources new, surplus and discontinued Honeywell parts — request a quote for price, condition and lead time.

Specifications
