Honeywell – PVL0000AS-ILC/U Spyder® Classic LON Programmable VAV Controller

Spyder® LON programmable VAV controllers are free topology transceiver (FTT) LonMark® compliant devices designed to control HVAC equipment. These controllers provide many options and advanced system features that allow state-of-the-art commercial building control. Each controller is programmable and configurable using the Niagara Framework® software. Spyder LON controllers require the Spyder programmable feature to be licensed in the WEBpro workbench tool and the Webs-AX™ JACE® Controller for programming and downloading. Spyder LON Models are also available as individually licensed controllers (ILC). The ILC versions are identical in design and capability in every detail except for the licensing. The built-in individual licensing of the Spyder ILCs allows them to be programmed and downloaded with any brand of the Niagara Workbench or JACE controller. The controllers are for use in variable air volume (VAV) applications. Each controller contains a host microcontroller to run the main HVAC application and a second microcontroller for LonWorks® network communications. Each controller provides flexible universal inputs for external sensors, digital inputs, and a combination of analog outputs and digital outputs. Features & Benefits:

Uses the Echelon® LonWorks network protocol

Free topology transceiver (FTT) high-speed 78 kilobit communications network

Capable of standalone operation, but can also use LonWorks Bus network communications.

Sylk™ bus for use with Sylk-enabled sensors

120 controllers per Q7751A,B Router when configured as a repeater

Function block engine allows the application designer to program the controller to perform a wide variety of HVAC applications

Significant event notification, periodic update capability, and failure detect (FD) when network inputs fail to be detected within their configurable time frame

Built-in zone control functions include a remote wall module interface and a scheduler

Easy user access to airflow sensor inputs

All wiring connections are made to removable terminal blocks to simplify controller installation and replacementCertifications:

UL/cUL (E87741) Listed under UL916 (Standard for Open Energy Management Equipment) with Plenum Rating

CSA (LR95329-3) Listed

Meets FCC Part 15, Subpart B, Class B (Radiated Emissions) Requirements

Canada: C108.8 (Radiated Emissions)

EU: EN 61000-6-1; 2001 (EU Immunity), EN 61000-6-3; 2001 (EU Emissions)

Honeywell PVL0000AS-ILC/U — Spyder® LON programmable VAV controllers are free topology transceiver (FTT) LonMark® compliant devices designed to control HVAC equipment. Each controller is programmable and configurable using the Niagara Framework® software. Discontinued by Honeywell — no longer in the current range. PartnerPLC sources new, surplus and discontinued Honeywell parts — request a quote for price, condition and lead time.
