Honeywell – OSI-RI-SS System Sensor OSI Intelligent Beam Detector
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | Honeywell Fire Detectors & Manual Call Points |
| Lifecycle | Active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
Shipping & availability
When can OSI-RI-SS be shipped?
OSI-RI-SS is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up OSI-RI-SS in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for OSI-RI-SS and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for OSI-RI-SS, subject to availability and destination.
The OSI-RI intelligent addressable reflector-type linear optical beam smoke detector is uniquely suited for protecting large open areas with high ceilings, where spot-type smoke detectors are difficult to install and maintain. Ideal applications are warehouses, atriums, aircraft hangers, sporting arenas and concert halls. The beam operates primarily on the principle of light obscuration using infrared. The OSI-RI detector is a combined transmitter/receiver that can be directly connected to an intelligent detector circuit in LiteSpeed® or CLIP mode.
Features & Benefits:
Loop-based unit
Combined transmitter/receiver unit
Wide 12° field of view
Fast, easy, and intuitive beam alignment indicated by LED directional arrows
50° horizontal and 20° vertical beam adjustment
Long range coverage of 16-328 ft (5-100m) is standard- no separate long-range kit required
Automatic sensitivity threshold level setting
Resistant to building movement- tolerates +/- 1° movement
Resistant to strong light sources- does not alarm when saturated by sunlight
Resistant to solid object intrusion
Remote test station capable for electronic simulated smoke test from ground level
Status LED indicators visible from the front and bottom
Automatic drift compensation
Paintable housing/cover
Removable plug-in terminal blocks
Built-in imager heater
Optional reflector heater kit available
Certifications:
UL/ULC Listed
FM: PR449231
CSFM: 7260-0559:0515
Honeywell System Sensor OSI-RI-SS — The OSI-RI is an intelligent addressable reflector-type linear optical beam smoke detector that is uniquely suited for protecting large open areas with high ceilings, where spot-type smoke detectors are difficult to install and maintain. PartnerPLC sources new, surplus and discontinued Honeywell parts — request a quote for price, condition and lead time.
Specifications
Product
| Lifecycle | Active |
| Brand line | System Sensor |
Others
| Brand | System Sensor |
| Product Type | Beam Detector |
| Detection Sensor Type | Beam |
