Home / Honeywell / Honeywell Access Control / INS-WX-485 INS-WX-485 Proximity Reader

Available on request

Honeywell – INS-WX-485 INS-WX-485 Proximity Reader

Name: Honeywell – INS-WX-485 INS-WX-485 Proximity Reader
Brand: Honeywell
SKU: INS-WX-485

MPN: INS-WX-485 · Brand: Honeywell

Price on request

Discontinued by Honeywell — we can still source the original INS-WX-485 (new, used or refurbished, subject to availability). Request a quote below.

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Honeywell Access Control
Lifecycle	Discontinued
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

Can I still buy the INS-WX-485 now that it is discontinued?

Yes. Honeywell has discontinued the INS-WX-485, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time.

When can INS-WX-485 be shipped?

INS-WX-485 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up INS-WX-485 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for INS-WX-485 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for INS-WX-485, subject to availability and destination.

The Vandal-proof PIN + PROX reader with backlit keys, 125Khz, water resistant, suitable for indoor and outdoor IP65 installations, optical tamper, reading distance about 80mm. Integrated RS485 communication module, 1 multi-balance input and 1 O / C output on board. It is seen by the CS600 as an LCD terminal therefore max. n ° 10 INS-WX-485 per line (to be subtracted from the LCD600S already present). Wall and / or box 503 installation. INS-WX-485 terminal is built and controlled for also be installed outdoors, on exposed sites directly to meteorological phenomena; the degree ofIP67 protection guarantees it against water infiltrations and humidity. The metal vandal-proof proximity terminal for Outdoor installation, degree of protection IP67, with integrated 485 line module, for connection to Central CS600. The reading distance of the cards is approx Three cm, the antenna is under the Notifier logo. Installations directly exposed to the solar radiation in environments where it can cause overheating above the allowed temperatures .NS-WX-485 in system terminal mode features Recognition of the operator by PIN, card proximity, or through combinations of the two systems. Possibility to exclude the PIN. Programmable Time-Out. Automatic execution of predefined functions. Manual execution of the functions associated with keys 1. Features & Benefits:

Horizontal 12-key backlit touch keyboard

EM4102 125 KHz proximity card reader

Four programmable LEDs

A LED for system signals

Buzzer for programmable sound signals

Double balanced input

A relay with 12Vdc-2A contact capacity

Optical Tamper

One quadruple balanced input

One open collector output (max 400 mA)Certifications:

UNI EN ISO 9001: 2008

Honeywell INS-WX-485 — The Vandal-proof PIN + PROX reader with backlit keys, 125Khz, water resistant, suitable for indoor and outdoor IP65 installations, optical tamper, reading distance about 80mm. Discontinued by Honeywell — no longer in the current range. PartnerPLC sources new, surplus and discontinued Honeywell parts — request a quote for price, condition and lead time.
