Honeywell H6ECM05

H6ECM Current Switch

MPN
H6ECM05
Price and lead time confirmed within 1 business day

Discontinued by Honeywell — we can still source the original H6ECM05 (new, used or refurbished, subject to availability). Request a quote below.

Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Honeywell parts? We buy surplus →

What is the Honeywell H6ECM05?

The H6ECM is a current sensitive switching device that monitors current (amperage) in the conductor passing through it. A change in amperage in the monitored conductor that crosses the switch (set point) causes the resistance of the FET status output to change state, similar to the action of a mechanical switch. The status output is suitable for connection to building controllers or other appropriate data acquisition equipment operating at up to 30 V. The product requires no external power supply to generate its output.Electrically Commutated Motors (ECMs) are increasingly common as more energy conservation measures are implemented. The ECM is a brushless DC motor that is supplied AC power, converts that power to DC current and uses electronic switching to control the motor rotation. The ECM motor shaft speed can be reduced to save energy, resulting in lower cost and less component wear. The H6ECM is optimized to provide meaningful proof of rotation which verifies that the ECM motor is operating as expected.

Features & Benefits:

High performance

Precise current trip point setting

Small size

Self-gripping iris

Status LEDs

Up to 1 Amp status output

Certifications:

UL508

Honeywell Alerton H6ECM05 — Current Switch by Alerton is optimized to provide meaningful proof of rotation which verifies that the ECM motor is operating as expected. Discontinued by Honeywell — no longer in the current range. PartnerPLC sources new, surplus and discontinued Honeywell parts — request a quote for price, condition and lead time.

Specifications

Product

LifecycleDiscontinued by Honeywell
Brand lineAlerton

Others

Output Signal1 A @ 30 /DC voltage alternating current
Minimum Operating Ambient Temperature-15 degree Celsius, 5 degree Fahrenheit
Maximum Operating Ambient Temperature140 degree Fahrenheit, 60 degree Celsius
BrandAlerton
Product TypeCurrent Switch Degrees Celsius

H6ECM05: frequently asked questions

Can I still buy the H6ECM05 now that it is discontinued?

Yes. Honeywell has discontinued the H6ECM05, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time.

When can H6ECM05 be shipped?

H6ECM05 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up H6ECM05 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for H6ECM05 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for H6ECM05, subject to availability and destination.
