Honeywell – H4P6RXXBK Trillium Wall Reader

Secure your property with an Onity RFID/Bluetooth®

Low Energy wallreader at perimeter doors, elevators,

parking areas, swimming pools, fitness facilities, and

other common areas. Perfect for interior or exterior

use, wall readers are programmable just like any Onity

lock. For elevator installations the wall reader can be

configured to incorporate a relay expansion control

board allowing access to multiple floors/zones from

one single reader.

Off-line card readers allow only authorized card

holders to gain access, and the audit trail retains the

last 500 openings.

On-line wall readers allow reception personnel to check

openings as well as to authorize or deny card access

in real time. Non-volatile memory supports an audit

trail of the last 8,000 openings, and an anti-passback

function is also incorporated.

The wallreader comes with a DirectKey™ module,

enabling a proven mobile key solution. It provides

secure wireless communication of credentials from

the user’s smartphone to a locking device, via

Bluetooth technology. With a smartphone app, not

only can guests securely access controlled areas, but

also their guest room.

Features & Benefits:

Compatible with Onity Trillium, ADVANCE or Serene

locking systems

Mobile access ready

Supports MIFARE Classic®, MIFARE Plus®, MIFARE

Ultralight® and MIFARE Ultralight C RFID

ADA compliant, ADA opening timer

Offline and Online wall reader control unit options

Tamper switch generates audit log

Certifications:

FCC, IC, CE, UL294

Honeywell Onity H4P6RXXBK — Onity RFID/Bluetooth® Low Energy wall reader provides additional access points in common areas. Perfect for interior or exterior use, wall readers are programmable just like any Onity lock. PartnerPLC sources new, surplus and discontinued Honeywell parts — request a quote for price, condition and lead time.

Specifications
