Honeywell – GL-004K MPS-950B Series

MPN: GL-004K · Brand: Honeywell

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Honeywell Fire Detectors & Manual Call Points
Lifecycle	Active
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

When can GL-004K be shipped?

GL-004K is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up GL-004K in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for GL-004K and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for GL-004K, subject to availability and destination.

General

The Notifier MPS Conventional Series manual stations provide

reporting for the NFS-320C, NFS2-640, and NFS2-3030 fire

alarm control panels; NFW-MPS series manual stations provide

reporting for FireWarden series panels. These high quality, die

cast metal manual stations include screw terminal connections,

and integrated break-glass rod. The alarm contact for the manual station is rated for 1A, 24VDC. The contacts are gold plated

to avoid the risk of corrosion.

The MPS Series manual stations are available as single or twostage for conventional systems. Models N-MPS-SC/SCC are

single-stage manual stations. Models N-MPS-2C/2CC (twostage models) are similar to the N-MPS-SC (single-stage models) except they contain an additional 2nd Stage normally open

key-switch. A 2nd stage key is supplied with each unit to activate

the 2nd Stage key-switch.

All models are available with screw terminal connectors and a

hex key for reset. Two-stage models also include a key-switch

and 2 keys. All conventional models mount on a single gang

box or on a single gang box with a plaster ring.

For surface mounting, use Notifier surface back-box MPS-BB

with all conventional manual stations.

Operation

The Notifier MPS Series manual stations are operated by pulling

the handle on the front of the station. To reset the manual station, open the manual station with the hex key (provided) and

place the handle in the normal upright position. Replace the

break-glass rod, and close the manual station front cover.

The N-MPS two-stage models include a key switch which is

located above the handle. Operation of the key-switch, when

connected to a separate alarm initiating circuit, will activate the

second stage of a two-stage alarm signaling system.

To reset the second stage activation, return the key-switch to the

original position before resetting the fire alarm control panel.

Models provided with an ancillary contact for mag-lock release,

will simultaneously release the locally connected mag-lock upon

pulling the handle on the front of the manual station. Features & Benefits:

Features

Constructed of high quality die-cast metal

Highly visible red enamel finish

English and French lettering

Single action pull lever design

Optional dual action lever kit

Integrated break-glass

Hex key resettable

Screw terminal connectors

Optional ancillary contact for local mag-lock release

Single-stage and two-stage models

Key-switch activation for second stage

Surface or semi-flush mounting

All conventional models mount on a standard single-gang

electrical box or a surface metal back-boxCertifications:

ULC listed: S7568

Honeywell GL-004K — MPS-950 Series Pull Stations provide manual fire reporting. The MPS-950 Series manual stations are non-coded, normally-open contacts, manual initiating alarm pull stations. PartnerPLC sources new, surplus and discontinued Honeywell parts — request a quote for price, condition and lead time.
