Honeywell FG-32-017

CFP-16NZ Agent Release Conventional Fire Alarm Control Panel

MPN
FG-32-017
Price and lead time confirmed within 1 business day
Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Honeywell parts? We buy surplus →

What is the Honeywell FG-32-017?

The CFP-16 Extinguishing Agent Releasing Panel is an 8 or 16 zone Fire Alarm Control Panel for extinguishing agent releasing application. The CFP-16 extinguishing agent release panel provides reliable fi re detection and protection for commercial, industrial and institutional buildings requiring extinguishing agent-based releasing.

The standard panel is equipped with 8 detection zones but may be extended to 16 Zones by the addition of an 8 Zone expansion module and incorporates one Extinguishing Agent Release zone module. The module provides for connection of visual warning devices and Local Control Stations (LCS)

The system can be configured for either single or dual activation (double interlock) prior to release. Adjustable time delays between second stage alarms and extinguishing agent release are also provided.

Features & Benefits:

8 Zones - expandable to 16 zones

80 character LCD display providing a simple user friendly interface

24 character programmable zone descriptor

Zones can be configured for a range of different device type functions

Outputs may be programmed for different functional and cause & effect requirements

Dual risk operation – from three risk inputs

Adjustable discharge delay timer

5A Extinguishing agent releasing device output

Local Control Station fitted to enclosure

Optional Pyrozone interface

Certifications:

AGENCY LISTINGS AND APPROVALS

Certifi ed to NZS4512:2010

FPA Register # NI/102

Honeywell FG-32-017 — 8 or 16 zone conventional FACP with Agent Release Module. PartnerPLC sources new, surplus and discontinued Honeywell parts — request a quote for price, condition and lead time.

Specifications

Product

LifecycleActive

Ordering codes

Part numbers on this product pageFG-32-017, FG-32-018
