Honeywell – ES-200XP ES-200XP Addressable Fire Alarm Control Panel FACP with Built-in Cellular Communicator

Fire-Lite's legacy of simple and reliable performance continues with the Fire-Lite's ES-XP Series fire alarm control panels (FACPs). The ES-200XP offers a complete turn-key fire safety solution by combining the dependable ES Series of addressable FACPs with a built-in dual path (IP/cellular), dual cellular (AT&T/Verizon) and dual listed (UL/ETL) 5G LTE-M cellular communicator. This combined solution reduces installation and labor costs, enables faster and more reliable central station reporting and provides complete line of site monitoring plus access to automated test and inspection reporting through Honeywell’s Connected Life Safety Services (CLSS) cloud solutions.

With support for up to 198 addressable devices with an extensive list of powerful features, the ES-200XP has a wide range of capabilities to provide superior value and flexibility.

Features & Benefits:

Hardware Features:

Single SLC that provides support for up to 198 addressable devices

Integrated CLSS Pathway Pro Communicator; dual SIM AT&T/Verizon networks with LTE-CAT-M1 5G technology

Upload/download panel programming database and flash firmware with USB thumb drive

Support for addressable multi-criteria fire and CO detector

Four programmable function keys

Auto-programming (learn mode) reduces installation time (reports two devices set to the same address)

Built in Class A capability for all 4 NACs; no optional card required

Trouble indication for SLC devices not programmed

Integrated SWIFT display driver and annunciator built-in to panel

Increased number of software zones

Notification appliance circuits have built-in sync for the industry’s leading manufacturers including System Sensor®, Wheelock®, and Gentex®

Hardware Benefits:

Reduces installation and labor costs with all-in-one solution of FACP with built-in CLSS Pathway Pro communicator

Saves time with 4 programmable buttons to automate routine tasks and allow for firmware upgrades and panel programming via a USB drive

Increases reliability and peace of mind with built-in communications

Saves money on SWIFT wireless installations over previous Fire-Lite panels with a built-in wireless display driver and annunciator

Integrated CLSS Pathway Communicator enables faster and more reliable central station reporting: can transmit signals to central stations up to 40 seconds faster than legacy dialer capture or legacy POTS communication methods primarily used in the market

CLSS Software Features:

CLSS Central Station Alerting provides code required transmission of fire alarm control panel events to central monitoring stations.

CLSS Site Manager provides a “bird’s eye” view of all your accounts and real-time information on event generation so you can diagnose before dispatch. Reduce unnecessary trips and improve your first-time fix rate.

CLSS Facility Manager provides your end users with event alerts via mobile app and access to asset information across multiple sites.

CLSS Contextual Information for First Responders shares contextual alarm information from the fire panel with first responder applications.

CLSS Compliance Manager digitizes the test and inspection process so you can easily generate standard or customizable reports through the web or mobile app (available in select markets).

Certifications:

UL

ETL

CSFM

FDNY

Honeywell Fire-Lite ES-200XP — The ES-200XP FACP comes with a built-in dual path (IP/cellular), dual cellular (AT&T/Verizon) and dual listed (UL/ETL) 5G LTE-M CLSS Pathway cellular communicator and supports up to 198 addressable devices in any combination of detectors or modules. PartnerPLC sources new, surplus and discontinued Honeywell parts — request a quote for price, condition and lead time.

Specifications
