Honeywell – CSSV1500N-154 CSSV1500N Series ASIL C current sensors, 1500 A, through-hole mounting with stainless steel bushing, 500 k baud rate, 3C4 CAN ID

Part of Honeywell's CSSV1500 Series Current Sensor range. The CSSV1500 Series Current Sensors are based on Honeywell's advanced multi-sensing scheme, a single power supply and an integrated CAN bus output. They are calibrated and temperature compensated using multipoint temperature characterization. This Honeywell's patented digital compensation technology enables a high degree of accuracy throughout the sensing range up to ±1500 A.The CSSV1500 Series is designed to meet Automotive Safety Integrity Level C (ASIL C) requirements for safety critical applications. These sensors have two independent sensing and data processing circuits for current sensing. The two processed data are checked for confidence. If they are within the set threshold range, the current data is outputted. If the threshold is exceeded, an alarm message is sent.

FEATURES

Higher accuracy, lower temperature drift

Enhanced EMC (Electromagnetic Compatibility ) performance

Designed to meet automotive Safety Integrity Level C (ASIL C) for the functional safety of road vehicle applications

Reliable and stable CAN bus output

Easy installation and software interface provide system integration convenience

CE certification; REACH and RoHS compliant

DIFFERENTIATION

Accuracy: Multi-point temperature characterization and calibration for improved accuracy over the temperature range

Magnetic immunity: Sensing configuration and optimized magnetic circuit allow for enhanced performance in diverse magnetic environments

ASIL-C Compliance: ASIL C for increased reliability in safety-critical applications

VALUE TO CUSTOMERS

Accurate: Designed to enable precise battery state measurement for improved user experience

Ease of use: Magnetic immunity allows for easy integration into different magnetic environments

Easy system integration: CAN communication is transmitted using international road vehicle standard ISO 11898. CAN 2.0A is the default protocol

APPLICATIONS

Current measurement for battery management systems in electrified vehicles (EV, HEV, PHEV, BEV)

Current leakage detection and fault isolation in charging systems

Current measurement in energy storage systems

Fault detection in heavy industrial equipmentDistributor Inventory

Honeywell CSSV1500N-154 — CSSV1500N Series ASIL C current sensors, 1500 A, through-hole mounting with stainless steel bushing, 500 k baud rate, 3C4 CAN ID (CSSV1500 Series Current Sensor). PartnerPLC sources new, surplus and discontinued Honeywell parts — request a quote for price, condition and lead time.
