Honeywell – 804956 Electronic module MCP small addressable

MPN: 804956 · Brand: Honeywell

Price on request

Discontinued by Honeywell — we can still source the original 804956 (new, used or refurbished, subject to availability). Request a quote below.

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Honeywell Fire Detectors & Manual Call Points
Lifecycle	Discontinued
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

Can I still buy the 804956 now that it is discontinued?

Yes. Honeywell has discontinued the 804956, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time.

When can 804956 be shipped?

804956 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 804956 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 804956 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 804956, subject to availability and destination.

Addressable electronic module for manual fire alarm actuation (as a manual fire call point in connection with housing Type 704950) or hazard alarm actuation. Suitable for use in the esserbus and powered loop with soft address coding, alarm latch and alarm indicator.

When the manual call point is triggered, the integrated red light-emitting diode (LED) is automatically activated and the yellow mechanical alarm indicator is visible in the upper window area.

Manual call point type A: direct operation (single action) in which the change to the alarm condition is automatic (i.e. without the need for further manual action) when the frangible element is broken or displaced.

The operation mode is displayed via the flashing green LED.

Without BUS connection, the detector operates as conventional MCP.

In difference to 804955, the MCP has no line isolator and no connection possibility for standard manual call points (D-line), but is equipped with an additional relay output.

The relay output is activated automatically when this MCP is triggered. The relay output can be programmed as a control zone in the customer data of the fire alarm control panel.

Features & Benefits:

Flat design

Plug-in connection terminals

Optional terminal

Triple key function: test, open, reset

Detectors that are not ready for operation can be marked with the "Out of order" label by reversing the enclosed glass pane

Certifications:

EN 54-11, type A

Honeywell ESSER 804956 — IQ8MCP electronic module w/o isolator, with relay. Discontinued by Honeywell — no longer in the current range. PartnerPLC sources new, surplus and discontinued Honeywell parts — request a quote for price, condition and lead time.
