Honeywell – 3719-16MM 3719-16MM-135KN,1AD,2U,6AG,15C:MODEL

MPN: 3719-16MM · Brand: Honeywell

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Honeywell Test & Measurement
Lifecycle	Active
Warranty	12-month (new) · 3-month (used/refurbished)
Datasheet	Manufacturer datasheet ↗

Shipping & availability

When can 3719-16MM be shipped?

3719-16MM is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 3719-16MM in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 3719-16MM and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 3719-16MM, subject to availability and destination.

Part of Honeywell's Model 3719 Bolt and engine mount force sensor range. The bolt force sensor is another unique transducer which is essentially a hollow-compression strain gage load cell. It is designed to be used with most strain gage indicators. The bolt force sensor is a three-piece assembly consisting of: 1. a large hardened and ground flat washer with one side beveled, 2. the sensor, and 3. a small hardened and ground washer. The three pieces are assembled for various applications.

The large washer isolates the sensor from the force application tool. The beveled hole in this washer, which always faces away from the sensor, provides clearance for the bolt head radius. When a torque wrench is used, a torque vs. clamp force curve can be generated. The 3719 bolt force sensor is designed for use in fastener testing where the compression loading of the sensor is induced by the tensile loading of the fastener. The bolt force sensor must be used with the size fastener for which it was designed.

Features

Compact

High output

Standard models for bolts size no. 6 thru 2 in and up to 20 mm

Sensor and washers - carpenter 440C stainless steel

Sensitive to neither bolt nor nut-applied torque

Honeywell 3719-16MM — 3719-16MM-135KN,1AD,2U,6AG,15C:MODEL (Model 3719 Bolt and engine mount force sensor). PartnerPLC sources new, surplus and discontinued Honeywell parts — request a quote for price, condition and lead time.
