Honeywell – 2102-50 Model 2102 Small Flanged Reaction Torque Transducer, 50 in-lb, 21 °C to 75 °C [70 °F to 170 °F] Temperature Compensation, Non-amplified (mvv), Amphenol MS3102A-14S-5P elect

Part of Honeywell's 2102 Series Rotary Measurement Systems range. Model 2102 small flanged reaction torque sensor is designed for installation between test pieces such as motors, switches, axles, or shafts and their mounting plate. These models operate and are calibrated in both clockwise and counterclockwise directions. Nickel-plated alloy steel construction enhances durability in harsh, industrial environments. These models have no moving parts and utilize four bonded strain gages on a special machined portion of the transducer to achieve a maximum non-linearity of 0.1 % over a wide dynamic range. Typical applications include tire braking, motor dynamometers, friction-skid testing, and twist measurement. 50 in-lb to 1,000 in-lb capacities.

Features

50 in-lb to 1000 in-lb capacities

0.1 % non-linearity and hysteresis

Reaction measurements designed to eliminate speed limitations

Reduced friction error

No maintenance of slip rings, bearings, or brushes

Compact, 'low mass' physical style

Honeywell 2102-50 — Model 2102 Small Flanged Reaction Torque Transducer, 50 in-lb, 21 °C to 75 °C [70 °F to 170 °F] Temperature Compensation, Non-amplified (mvv), Amphenol MS3102A-14S-5P electrical connector, radial electrical exit orientation (2102 Series Rotary Measurement Systems). PartnerPLC sources new, surplus and discontinued Honeywell parts — request a quote for price, condition and lead time.

Specifications
