Honeywell 022234

Escape Route Technology - 1338 Stand Alone Compact Control Terminal Series

MPN
022234
Price and lead time confirmed within 1 business day
Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Honeywell parts? We buy surplus →

What is the Honeywell 022234?

The compact emergency exit control terminal combines a control unit and a door terminal. This allows for the implementation of an emergency exit locking system with minimal effort, which of course fully complies with the building regulations for electrical locking systems for doors in escape routes.

Features & Benefits:

Emergency release button with cover (illuminated/forced opening)

Key switch for door control

Acoustic signal

LED door status indicator: locked/unlocked/alarm

3 inputs / 2 outputs

Profile half cylinder and 3 keys, keyed differentlyTechnical Data

Nominal connection voltage: 230 V AC

Nominal operating voltage: 24 V DC

Independent current consumption: max. 150 mA

External current consumption: max. 450 mA

Relay contact rating: max. 24 V/1 A with resistive load

Protection class according to DIN 40050: IP 40

Humidity class: F (according to DIN 40050)

Ambient temperature: 0 - 35 °C

Indication: LEDs red, green, yellow

Installation position: vertical

Profile cylinder locking bolt position: 90° left (profile half cylinder)

Length A: 30.5 mm (Profile half cylinder)

Dimensions (L x W x H) 92.5 x 250 x 98 mm

Honeywell 022234 — Stand-alone Compact green emergency exit control unit, model 1338-14, 230VAC, including: 1 x Exit warning sign. PartnerPLC sources new, surplus and discontinued Honeywell parts — request a quote for price, condition and lead time.

Specifications

Product

LifecycleActive
