Danfoss WV06077F032

COUPLING,W6000,F,1"1/2,SS,-24BSP,FVMQ

MPN: WV06077F032
Category: Danfoss Hansen® quick disconnect couplings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss WV06077F032?

Danfoss COUPLING,W6000,F,1"1/2,SS,-24BSP,FVMQ, manufacturer part number WV06077F032. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Angle shape	Straight
Body size	1 1/2"
Brand	Danfoss
End size 1	-24
End Type 1	Female BSPP port washer seal.
Hex size 1 IN	3.460
Item type	Female half
Latch type	Screw to connect
Product height in	3.940
Product height mm	100.076
Product length in	6.810
Product length mm	172.974
Product material	1.4418 Stainless steel
Product width in	3.940
Product width mm	100.076
Seal material	Silicone
Sub brand	Gromelle
Thread size 1	G 1 1/2
Valve type	2 way
Working pressure max psi	4350
Working temperature max F	356
Working temperature min F	-67
