Danfoss WAL615366

TUBE FTG, EGESD 16 S/R3/4-WD VI A4GS

MPN: WAL615366
Category: Tube fittings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via

What is the Danfoss WAL615366?

Danfoss TUBE FTG, EGESD 16 S/R3/4-WD VI A4GS, manufacturer part number WAL615366. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Angle shape	Straight
Brand	Danfoss
Complete connector	No
End size 2	16S
End Type 1	Male 1179-2 BSPP type E (S)
End Type 2	24 deg. DKO swivel heavy duty
Finish plating	Guardian Seal
Hex size 1 MM	27.000
Hex size 2 MM	30.000
Item type	Adjustable connector
Model Code 1	EGESD 16 S/R3/8-WD A4GS
Product height in	1.260
Product height mm	32.000
Product length in	1.969
Product length mm	50.000
Product material	Carbon steel
Product serial name	EGESD … R-WD
Product width in	1.260
Product width mm	32
Seal material	Nitrile (NBR)
Sub brand	Waltech
Thread size 1	G 3/8 A
Thread size 2	M24x1.5
Tube outside diameter 2 MM	16.0
Working pressure bar	630.0
Working temperature max C	120
Working temperature min C	-40
