Danfoss ML8DBS100FBS292

COUPLING,MLDB,F,1",SS,-16BSP,EPDM

MPN: ML8DBS100FBS292
Category: Danfoss Hansen® quick disconnect couplings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss ML8DBS100FBS292?

Danfoss COUPLING,MLDB,F,1",SS,-16BSP,EPDM, manufacturer part number ML8DBS100FBS292. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Angle shape	Straight
Body size	1"
Brand	Danfoss
End size 1	-16
End Type 1	Female BSPP port washer seal.
Hex size 1 IN	1.970
Item type	Female half
Latch type	Push to connect
Product material	Stainless steel
Safety locking mechanism	Sleeve lock
Seal material	Ethylene propylene (EPDM)
Sub brand	Hansen
Thread size 1	G 1
Valve type	2 way
Working pressure max psi	360
Working temperature max F	302
Working temperature min F	-40
