Danfoss HA0GKE

CYLINDER N5 B6.00 R3.50 S3.160 IN M14, N5P-6.00X3.16-N-3.50-2M-X-X-X-1-1

MPN: HA0GKE
Category: Hydraulic cylinders

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss HA0GKE?

Danfoss CYLINDER N5 B6.00 R3.50 S3.160 IN M14, N5P-6.00X3.16-N-3.50-2M-X-X-X-1-1-HA0GKE, manufacturer part number HA0GKE. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Brand	Vickers by Danfoss
Bore Diameter	6.00 inch
Mounting style	Cap rectangular
Rod seal	Custom rod seal
Piston seal	Custom piston seal
Port Type	Custom port
Port Size	SAE#16
Head Port Location	Head port location1
Cap Port Location	Cap port location 1
Cushion location	Non-cushioned
Customer end thread length	2.75
Customer end thread size	M64X6
Customer part number	10384781
First rod end type	Male modified
Model Code 1	N5P-6.00X3.16-N-3.50-2M-X-X-X-
Model Code 2	1-1-HA0GKE
Net stroke length	3.16 inch
Paint specification	Black paint
Rod flats	2 flats
Series	N5 Series-Hydraulic
Stop tube IN	0.00
Sub brand	Hydro-Line
Test pressure PSI	3000
Working pressure PSI	3000.00
