Danfoss H26506BU-600R

HOSE-BOS, H265, -6, AIR/MULTI, BU, 600FT

MPN
H26506BU-600R
Price and lead time confirmed within 1 business day
Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss H26506BU-600R?

Danfoss HOSE-BOS, H265, -6, AIR/MULTI, BU, 600FT, manufacturer part number H26506BU-600R. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Specifications

Abrasion resistancePremium
ApplicationLow pressure air
Bend radius min (inch)1.250
Bend radius min (mm)31.800
BrandBoston by Danfoss
Burst pressure (bar)96
Burst pressure (psi)1400
ColorBlue
CompliancesASTM D380
ConductivityConductive
Construction2 Ply spiral
Cover materialThermoplastic
Fixed Length182.900
Inside diameter (inch)0.38
Inside diameter (mm)9.50
Lay line styleInk jet
Length (in)7200.00000
Outside diameter (inch)0.65
Outside diameter (mm)16.51
Package formReel
Product height in0.380
Product height mm9.500
Product width in0.380
Product width mm9.500 mm
Qualified hose fittingsE Series
Reinforcement materialFabric
SeriesH265 Series
Size-6
Tube materialPolyvinyl chloride (PVC)
Tube wall thickness (inch)0.13
Tube wall thickness (mm)3.30
Working pressure max (bar)24
Working pressure max (psi)350
Working temperature max (C)65
Working temperature max (F)150.0
Working temperature min (C)-29
Working temperature min (F)-20.0

H26506BU-600R: frequently asked questions

When can H26506BU-600R be shipped?

H26506BU-600R is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up H26506BU-600R in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for H26506BU-600R and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for H26506BU-600R, subject to availability and destination.
