Danfoss FF3056-1212S

ADAPTER 90 DEGREE MALE PIPE / FEMALE STC

MPN: FF3056-1212S
Category: Adapters and swivel joints

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss FF3056-1212S?

Danfoss ADAPTER 90 DEGREE MALE PIPE / FEMALE STC, manufacturer part number FF3056-1212S. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

EAN/UPC	678146038555
Angle shape	90 Degree
Brand	Danfoss
Drop dimension IN	1.650
Drop dimension MM	41.90
End Type 1	Female STC connector
End Type 2	Male pipe (NPTF)
Finish plating	Dura-Kote
Item type	Adapter-elbow
Product material	Carbon steel
Thread sealant	No
Tube outside diameter 1 IN	0.810
Tube outside diameter 1 MM	20.6
Tube outside diameter 2 IN	0.720
Tube outside diameter 2 MM	18.3
Working pressure bar	34.0
Working pressure psi	500
Working temp max C	204
Working temp max F	400
Working temp min C	-54
Working temp min F	-65

FF3056-1212S: frequently asked questions

When can FF3056-1212S be shipped?

FF3056-1212S is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up FF3056-1212S in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for FF3056-1212S and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for FF3056-1212S, subject to availability and destination.
