OTHER, KITS ITEC P/N 3845189C93
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | Adapters and swivel joints |
| Lifecycle | active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
Shipping & availability
When can FF15332-01 be shipped?
FF15332-01 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up FF15332-01 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for FF15332-01 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for FF15332-01, subject to availability and destination.
Danfoss OTHER, KITS ITEC P/N 3845189C93, manufacturer part number FF15332-01. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.
Specifications
Specifications
| Application | Air, Fuel, Gasoline, Lubricating oils, Oil cooler |
| Brand | Aeroquip by Danfoss |
| Fitting angle shape 1 | Straight |
| Fitting angle shape 2 | Straight |
| Fitting end size 1 | Size 06 |
| Fitting end size 2 | Size 06 |
| Fitting hex | Fitting(s) to have inch nut hex and/or nipple hex |
| Fitting material | ZINC NICKEL PLATED STEEL, 240 HOURS WHITE CORROSION AND 620 HOURS RED RUST CORROSION. |
| Fitting series | TTC - through the cover |
| Fittings end type 1 | JIC Female 37° |
| Fittings end type 2 | JIC Female 37° |
| HA Certificate of compliance | None |
| HA Length UOM | Metric mm |
| HA Packaging | Standard Packaging |
| Hose series | FC699 Series |
| Hose size | Size 08 |
| Legacy fitting part number 1 | 1AA6FJ4TZ |
| Legacy fitting part number 2 | 1AA6FJ4TZ |
| Overall length IN | 3.8 |
| Overall length MM | 96 |
| Thread size 1 | 9/16-18 UNF |
| Thread size 2 | 9/16-18 UNF |
