Danfoss FCU1003

HOSE-AER, FCU, -10, 3FT, RL, FUEL,GY

MPN
FCU1003
Price and lead time confirmed within 1 business day
Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss FCU1003?

Danfoss HOSE-AER, FCU, -10, 3FT, RL, FUEL,GY, manufacturer part number FCU1003. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Specifications

EAN/UPC678146023377
Abrasion resistancePremium
ApplicationVehicle air brake lines
Bend radius min (inch)4.000
Bend radius min (mm)101.600
BrandAeroquip by Danfoss
Burst pressure (bar)140
Burst pressure (psi)2000
ColorBlack
CompliancesASTM D380
ConductivityConductive
Construction2 Ply braid
Cover materialPolyester (PET)
Inside diameter (inch)0.56
Inside diameter (mm)14.20
Lay line styleInk transfer
Length (in)36.00000
Length (mm)914.40000
Outside diameter (inch)0.80
Outside diameter (mm)20.32
Package formReel
Product height in0.560
Product height mm14.200
Product width in0.560
Product width mm14.200 mm
Qualified hose fittingsReusable
Reinforcement materialFabric
SeriesFCU Series
Size-10
Tube materialChlorinated Polyethylene (CPE)
Tube wall thickness (inch)0.06
Tube wall thickness (mm)1.40
Vacuum rating (inHg)20
Vacuum rating (mmHg)508.00
Working pressure max (bar)35
Working pressure max (psi)500
Working temperature max (C)149
Working temperature max (F)300.0
Working temperature min (C)-43
Working temperature min (F)-45.0

FCU1003: frequently asked questions

When can FCU1003 be shipped?

FCU1003 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up FCU1003 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for FCU1003 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for FCU1003, subject to availability and destination.
