Danfoss FCN1215

HOSE-AER, FCN, -12, 15FT, RL, R6,GY

MPN
FCN1215
Price and lead time confirmed within 1 business day
Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss FCN1215?

Danfoss HOSE-AER, FCN, -12, 15FT, RL, R6,GY, manufacturer part number FCN1215. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Specifications

EAN/UPC678146010797
Abrasion resistanceStandard
ApplicationAir
Bend radius min (inch)6.000
Bend radius min (mm)152.400
BrandAeroquip by Danfoss
Burst pressure (bar)96
Burst pressure (psi)1400
ColorBlack
CompliancesSAE 100R6
Conditional temp rangeAir not to exceed 250F
ConductivityConductive
Construction1 Ply braid
Cover materialChlorinated Polyethylene (CPE)
Impulse cycle (cycles)300000
Inside diameter (inch)0.75
Inside diameter (mm)19.00
Lay line styleInk jet
Length (in)180.00000
Length (mm)4572.00000
Outside diameter (inch)1.03
Outside diameter (mm)26.16
Package formReel
Product height in0.750
Product height mm19.000
Product width in0.750
Product width mm19.000 mm
Qualified hose fittingsGlobal skive
Reinforcement materialFabric
SeriesFCN Series
Size-12
Tube materialChlorinated Polyethylene (CPE)
Vacuum rating (inHg)18
Vacuum rating (mmHg)457.20
Working pressure max (bar)24
Working pressure max (psi)350
Working temperature max (C)149
Working temperature max (F)300.0
Working temperature min (C)-40
Working temperature min (F)-40.0

FCN1215: frequently asked questions

When can FCN1215 be shipped?

FCN1215 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up FCN1215 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for FCN1215 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for FCN1215, subject to availability and destination.
