Danfoss FCN0603

HOSE-AER, FCN, -6, 3FT, RL, R6,GY

MPN
FCN0603
Price and lead time confirmed within 1 business day
Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss FCN0603?

Danfoss HOSE-AER, FCN, -6, 3FT, RL, R6,GY, manufacturer part number FCN0603. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Specifications

EAN/UPC678146018588
Abrasion resistanceStandard
ApplicationAir
Bend radius min (inch)3.000
Bend radius min (mm)76.200
BrandAeroquip by Danfoss
Burst pressure (bar)112
Burst pressure (psi)1600
ColorBlack
CompliancesSAE 100R6
Conditional temp rangeAir not to exceed 250F
ConductivityConductive
Construction1 Ply braid
Cover materialChlorinated Polyethylene (CPE)
Impulse cycle (cycles)300000
Inside diameter (inch)0.38
Inside diameter (mm)9.50
Lay line styleInk jet
Length (in)36.00000
Length (mm)914.40000
Outside diameter (inch)0.62
Outside diameter (mm)15.75
Package formReel
Product height in0.380
Product height mm9.500
Product width in0.380
Product width mm9.500 mm
Qualified hose fittingsGlobal skive
Reinforcement materialFabric
SeriesFCN Series
Size-6
Tube materialChlorinated Polyethylene (CPE)
Vacuum rating (inHg)28
Vacuum rating (mmHg)711.20
Working pressure max (bar)28
Working pressure max (psi)400
Working temperature max (C)149
Working temperature max (F)300.0
Working temperature min (C)-40
Working temperature min (F)-40.0
