Danfoss FCF0803

HOSE-AER, FCF, -8, 3FT, RL, AC,GY

MPN: FCF0803
Category: Aeroquip performance products

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss FCF0803?

Danfoss HOSE-AER, FCF, -8, 3FT, RL, AC,GY, manufacturer part number FCF0803. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

EAN/UPC	678146011305
Abrasion resistance	Premium
Application	Air conditioning
Bend radius min (inch)	5.250
Bend radius min (mm)	133.000
Brand	Aeroquip by Danfoss
Burst pressure (bar)	138
Burst pressure (psi)	2000
Color	Stainless steel
Compliances	ASTM D471
Conductivity	Conductive
Construction	1 Wire Braid
Cover material	Stainless steel
Impulse cycle (cycles)	150000
Inside diameter (inch)	0.42
Inside diameter (mm)	10.70
Lay line style	Ink transfer
Length (in)	36.00000
Length (mm)	914.40000
Outside diameter (inch)	0.56
Outside diameter (mm)	14.22
Package form	Reel
Product height in	0.420
Product height mm	10.700
Product width in	0.420
Product width mm	10.700 mm
Qualified hose fittings	A/C fittings
Reinforcement material	Brass plated steel wire
Series	FCF Series
Size	-8
Tube material	Nylon 11
Working pressure max (bar)	34
Working pressure max (psi)	500
Working temperature max (C)	121
Working temperature max (F)	250.0
Working temperature min (C)	-40
Working temperature min (F)	-40.0
