Hose Marine CEX ITEM MIL-DTL-13444TyIII
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | Marine and military |
| Lifecycle | active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
Shipping & availability
When can FC173-10 be shipped?
FC173-10 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up FC173-10 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for FC173-10 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for FC173-10, subject to availability and destination.
Danfoss Hose Marine CEX ITEM MIL-DTL-13444TyIII, manufacturer part number FC173-10. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.
Specifications
Specifications
| Abrasion resistance | Standard |
| Application | Air, Diesel fuel, Gasoline, Lubricating oils, Water |
| Bend radius min (inch) | 2.250 |
| Bend radius min (mm) | 57.150 |
| Burst pressure (bar) | 241 |
| Burst pressure (psi) | 3500 |
| Color | Black |
| Construction | 2 Ply braid |
| Inside diameter (inch) | 0.52 |
| Inside diameter (mm) | 13.21 |
| Lay line style | Ink jet |
| Matr grp for sales restriction | Country Excluded Products |
| Outside diameter (inch) | 0.85 |
| Outside diameter (mm) | 21.69 |
| Series | FC173 Series |
| Size | -10 |
| Tube wall thickness (inch) | 0.19 |
| Tube wall thickness (mm) | 4.83 |
| Working pressure max (bar) | 60 |
| Working pressure max (psi) | 875 |
| Working temperature max (C) | 65 |
| Working temperature max (F) | 149.0 |
| Working temperature min (C) | -44 |
| Working temperature min (F) | -48.0 |
