Danfoss FBN0800

HOSE-AER, FBN, -8, PRFM

MPN
FBN0800
Price and lead time confirmed within 1 business day
Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss FBN0800?

Danfoss HOSE-AER, FBN, -8, PRFM, manufacturer part number FBN0800. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Specifications

EAN/UPC678146119247
ApplicationAir
Bend radius min (inch)4.000
Bend radius min (mm)101.600
BrandAeroquip by Danfoss
Burst pressure (bar)112
Burst pressure (psi)1600
ColorBlack
CompliancesSAE 100R6
Conditional temp rangeAir not to exceed 250F
Construction1 Ply braid
Cover materialChlorinated Polyethylene (CPE)
Impulse cycle (cycles)300000
Inside diameter (inch)0.50
Inside diameter (mm)12.70
Lay line styleInk jet
Outside diameter (inch)0.78
Outside diameter (mm)19.81
Package formBulk
Product height in0.500
Product height mm12.700
Product width in0.500
Product width mm12.700 mm
Qualified hose fittingsSocketless
Reinforcement materialFabric
SeriesFBN Series
Size-8
Tube materialChlorinated Polyethylene (CPE)
Vacuum rating (inHg)28
Vacuum rating (mmHg)711.20
Working pressure max (bar)28
Working pressure max (psi)400
Working temperature max (C)149
Working temperature max (F)300.0
Working temperature min (C)-40
Working temperature min (F)-40.0

FBN0800: frequently asked questions

When can FBN0800 be shipped?

FBN0800 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up FBN0800 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for FBN0800 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for FBN0800, subject to availability and destination.
