Danfoss EHS010-32RD

HOSE-BOS, EHS010, -32, STEAM, RD

MPN: EHS010-32RD
Category: Industrial hose and fittings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via

What is the Danfoss EHS010-32RD?

Danfoss HOSE-BOS, EHS010, -32, STEAM, RD, manufacturer part number EHS010-32RD. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Abrasion resistance	Standard
Application	Steam for cleaning equipment
Bend radius min (inch)	16.000
Bend radius min (mm)	408.000
Brand	Boston by Danfoss
Burst pressure (bar)	100
Burst pressure (psi)	1450
Color	Red
Conductivity	Conductive
Cover material	EPDM
Inside diameter (inch)	2.00
Inside diameter (mm)	50.80
Lay line style	Embossed
Outside diameter (inch)	2.64
Outside diameter (mm)	67.00
Package form	Bulk
Product height in	2.000
Product height mm	50.800
Product width in	2.000
Product width mm	50.800 mm
Qualified hose fittings	Boss male
Reinforcement material	Brass plated steel wire
Series	EHS010 Series
Size	-32
Tube material	EPDM
Working pressure max (bar)	10
Working pressure max (psi)	145
Working temperature max (C)	203
Working temperature max (F)	398.0
Working temperature min (C)	-40
Working temperature min (F)	-40.0
