SOCKET-PERM, K/24, CS

Name: SOCKET-PERM, K/24, CS
Brand: Danfoss (Drives)
SKU: DBK24

MPN: DBK24 · Brand: Danfoss (Drives)

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Hose machines, tools, and accessories
Lifecycle	active
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

When can DBK24 be shipped?

DBK24 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up DBK24 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for DBK24 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for DBK24, subject to availability and destination.

Danfoss SOCKET-PERM, K/24, CS, manufacturer part number DBK24. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

A dimension IN	3.350
A dimension MM	85.090
Angle shape	Straight
Brand	Winner Duffield by Danfoss
Compatible hose ID IN	1.500
Compatible hose ID MM	38.100
Construction Style	Swage
End type 1	Female compression
End type 2	Line/hose/tube
Finish plating	Zinc plating
Hose size	-24
Inside diameter IN	2.080
Inside diameter MM	52.830
Product height in	2.650
Product height mm	67.310
Product length in	3.350
Product length mm	85.090
Product material	Carbon steel
Product width in	2.650
Product width mm	67.310 mm
Thread sealant	No
Working temperature max C	121
Working temperature min C	40
Working temperature min F	40
