Danfoss B6HP31SL

COUPLING,HK,F,3/4,B,-12NPTF,NBR

MPN: B6HP31SL
Category: Danfoss Hansen® quick disconnect couplings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss B6HP31SL?

Danfoss COUPLING,HK,F,3/4,B,-12NPTF,NBR, manufacturer part number B6HP31SL. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

EAN/UPC	678146161901
Air inclusion max cc	11.50
Air inclusion max in3	0.70
Angle shape	Straight
Application	Agriculture, Chemical, Construction, Fluid transfer, Food and beverage, General industry, Hvac, Hydraulics, Nuclear, Oil and gas, Transportation, Trucks
Body size	3/4
Certifications	ISO 7241-1 Series B
Connection style	Manual connect
End size 1	-12
End size 2	-12
End Type 1	Female Push to Connect
End Type 2	Female pipe (NPTF)
Flow rate GPM	26.00
Flow rate LPM	98.42
Fluid compatibility	Hydraulic fluid
Fluid loss cc	9.30000
Fluid loss in3	0.56800
Hex size 1 IN	1.310
Hex size 1 MM	33.274
Item type	Female half
Latch type	Push/pull
Product length in	3.480
Product material	Brass
Safety locking mechanism	Sleeve lock
Seal material	Nitrile (NBR)
Thread size 1	3/4-14 NPTF
Valve type	2 way
Working pressure max psi	2000
Working pressure max BAR	138.00
Working temperature max C	121
Working temperature max F	250
Working temperature min C	-40
Working temperature min F	-40
