Danfoss B2T17
COUPLING,ST,M,1/4,B,-4BARB,NBR
- MPN
- B2T17
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the Danfoss B2T17?
Danfoss COUPLING,ST,M,1/4,B,-4BARB,NBR, manufacturer part number B2T17. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.
Specifications
Specifications
| EAN/UPC | 678146106933 |
| Angle shape | Straight |
| Application | Chemical, Fluid transfer, Food and beverage, Injection moulding, Marine, Medical, Pressure washing, Steam cleaning |
| Body size | 1/4 |
| Burst pressure min bar | 1434 |
| Burst pressure min psi | 20800 |
| Connection style | Manual connect |
| End Type 1 | Male push to connect |
| Flow rate GPM | 5.60 |
| Flow rate LPM | 21.20 |
| Fluid compatibility | Versatile fluid |
| Item type | Male half |
| Latch type | Push/pull |
| Product length in | 1.930 |
| Product material | Brass |
| Safety locking mechanism | None |
| Seal material | Nitrile (NBR) |
| Valve type | Straight thru |
| Working pressure max psi | 5200 |
| Working pressure max BAR | 359.00 |
| Working temperature max C | 121 |
| Working temperature max F | 250 |
| Working temperature min C | -40 |
| Working temperature min F | -40 |
