Danfoss B23AS37FBS

COUPLING,Auto-F,F,1/4,B,-6BSPP,NBR

MPN: B23AS37FBS
Category: Danfoss Hansen® quick disconnect couplings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss B23AS37FBS?

Danfoss COUPLING,Auto-F,F,1/4,B,-6BSPP,NBR, manufacturer part number B23AS37FBS. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

EAN/UPC	678146106506
Angle shape	Straight
Body size	1/4
Burst pressure min bar	41
Burst pressure min psi	600
Compliances	A-A-59439
Connection style	Automatic connect
End size 1	-6
End size 2	-6
End Type 1	Female Push to Connect
End Type 2	Female BSPP swivel
Flow rate GPM	209.22
Flow rate LPM	791.98
Fluid compatibility	Compressed air
Hex size 1 IN	0.810
Hex size 1 MM	20.574
Item type	Female half
Latch type	Push/pull
Product length in	2.020
Product material	Brass
Safety locking mechanism	Sleeve lock
Seal material	Nitrile (NBR)
Thread size 1	G 3/8
Thread size 2	G 3/8
Working pressure max psi	150
Working pressure max BAR	10.00
Working temperature max C	121
Working temperature max F	250
Working temperature min C	-40
Working temperature min F	-40
