Danfoss B1H11NV

COUPLING,HK,F,1/8,B,-2NPTF,NBR,NO VA

MPN: B1H11NV
Category: Danfoss Hansen® quick disconnect couplings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss B1H11NV?

Danfoss COUPLING,HK,F,1/8,B,-2NPTF,NBR,NO VA, manufacturer part number B1H11NV. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

EAN/UPC	678146161154
Air inclusion max cc	0.60
Air inclusion max in3	0.04
Angle shape	Straight
Application	Agriculture, Chemical, Construction, Fluid transfer, Food and beverage, General industry, Hvac, Hydraulics, Nuclear, Oil and gas, Transportation, Trucks
Body size	1/8
Brand	Danfoss
Certifications	ISO 7241-1 Series B
Connection style	Manual connect
End size 1	-2
End size 2	-2
End Type 1	Female Push to Connect
End Type 2	Female pipe (NPTF)
Flow rate GPM	0.80
Flow rate LPM	3.03
Fluid compatibility	Hydraulic fluid
Fluid loss cc	0.50000
Fluid loss in3	0.03100
Hex size 1 IN	0.560
Hex size 1 MM	14.224
Item type	Female half
Latch type	Push/pull
Product length in	1.910
Product material	Brass
Safety locking mechanism	None
Seal material	Nitrile (NBR)
Sub brand	Hansen
Thread size 1	1/8-27 NPTF
Valve type	2 way
Working pressure max psi	3000
Working pressure max BAR	207.00
Working temperature max C	121
Working temperature max F	250
Working temperature min C	-40
Working temperature min F	-40
