Danfoss 90011-16Z

HOSE NIPPLE, 2P/16, P3/16, CS, STR

MPN: 90011-16Z
Category: Braided hose and fittings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 90011-16Z?

Danfoss HOSE NIPPLE, 2P/16, P3/16, CS, STR, manufacturer part number 90011-16Z. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

A dimension IN	4.488
A dimension MM	114.000
Angle shape	Straight
Brand	Winner by Danfoss
Compatible hose ID IN	1.000
Compatible hose ID MM	25.400
Compatible hoses	EC110, EC210, FC686, FC687, GH663, GH781, GH793
Construction Style	Crimp
End Type 1	Line/hose/tube
End Type 2	Line/hose/tube
Finish plating	Zinc plating
Hose cut off factor IN	2.125
Hose cut off factor MM	54.000
Hose size	-16
Inside diameter IN	0.826
Inside diameter MM	21.000
Product height in	1.023
Product height mm	26.000
Product length in	4.488
Product length mm	114.000
Product material	Carbon steel
Product width in	1.023
Product width mm	26
Thread sealant	No
Working temperature max C	100
Working temperature max F	212
Working temperature min C	-40
Working temperature min F	-40

90011-16Z: frequently asked questions

When can 90011-16Z be shipped?

90011-16Z is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 90011-16Z in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 90011-16Z and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 90011-16Z, subject to availability and destination.
