Danfoss 87391-24-24H75Z

Fitting-nipple

MPN
87391-24-24H75Z
Price and lead time confirmed within 1 business day
Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 87391-24-24H75Z?

Danfoss fitting-nipple, manufacturer part number 87391-24-24H75Z. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Specifications

Angle shape90 Degree
BrandWinner by Danfoss
Compatible hose ID IN1.500
Compatible hose ID MM38.100
Compatible hoses EC110, EC210, FC686, FC687, GH663, GH781, GH793
Construction StyleCrimp
Drop dimension IN2.953
Drop dimension MM75.00
End size 1-24
End size 2-24
End Type 2Line/hose/tube
Hose cut off factor IN4.307
Hose cut off factor MM109.400
Hose size-24
Inside diameter IN1.260
Inside diameter MM32.000
Product height in3.839
Product height mm97.500
Product length in8.171
Product length mm207.551
Product materialCarbon steel
Product width in2.374
Product width mm60.3
Thread sealantNo
Working pressure max BAR207
Working pressure max PSI3002

87391-24-24H75Z: frequently asked questions

When can 87391-24-24H75Z be shipped?

87391-24-24H75Z is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 87391-24-24H75Z in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 87391-24-24H75Z and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 87391-24-24H75Z, subject to availability and destination.
