Danfoss 868286

CT5 060A F 50 UB AU, CT5060AF50UBAU

MPN: 868286
Category: Industrial valves

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 868286?

Danfoss CT5 060A F 50 UB AU, CT5060AF50UBAU, manufacturer part number 868286. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Actuation Type	Solenoid operated
Adjustment range	100-210 bar (1500-3000 psi)
Adjustment type	Wrench
Brand	Vickers by Danfoss
Design Series	50 Series
Drain	Internal
Electrical connection	ISO4400 (Din 43650) Connector
Flow rate lpm	227.0
Flow rate USGPM	60.0
Fluid Cleanliness	19/17/14 Micron
Fluid compatibility	Petroleum oils
Gauge port thread	0.4375-20 UNF-2B
Interface	1.0625-12 UF-2B
Leakage	Standard
Manual override	Plain
Maximum pressure BAR	210
Maximum pressure PSI	3000
Model Code 1	CT5060AF50UBAU
Performance	Standard
Product height in	9.540
Product height mm	242.316
Product length in	5.770
Product length mm	146.558
Product width in	3.280
Product width mm	83.312
Remote control	Yes
Seal material	Nitrile
Size	Size 06
Special feature	None
Spring Arrangement	Spring offset
Stage	Two stage
Tank pressure bar	100
Tank pressure PSI	1450
Valve Mount Type	NPTF threads
Valve type	Pilot operated relief valve
Working temperature max C	70
Working temperature max F	158
Working temperature min C	-20
Working temperature min F	-4

868286: frequently asked questions

When can 868286 be shipped?

868286 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 868286 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 868286 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 868286, subject to availability and destination.
