Danfoss 852AN00020B

KBS2-05-05-NS-11-E-CO-A-NS-VSC-NS-002-10, KBS20505NS11ECOANSVSCNS00210

MPN: 852AN00020B
Category: Industrial valves

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 852AN00020B?

Danfoss KBS2-05-05-NS-11-E-CO-A-NS-VSC-NS-002-10, KBS20505NS11ECOANSVSCNS00210, manufacturer part number 852AN00020B. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

A Port flow LPM	100.00
A Port flow USGPM	26.60
Actuation Type	Solenoid controlled
B Port flow LPM	100.00
B Port flow USGPM	26.60
Brand	Vickers by Danfoss
Build orientation	Solenoid at B port side
Coil voltage	24 Volt DC
Command input	+/-10V Command +/-10V feedback
Communication protocol	CANopen
Current	3.7 amp
Design Series	10 Series
Electrical Connection	Electrical (PE7) 7 pin electrical plug with mating half
Feedback sensor	Yes
Fluid Cleanliness	17/15/12 micron
Fluid compatibility	Antiwear hydraulic oils and non alkyl-based Phosphate Esters
Interface	ISO4401-05/NFPA D05/CETOP 5/NG10
Manual override	None
Model Code 1	KBS20505NS11ECOANSVSCNS00210
On board electronics	Yes
Performance	Servo
Pressure drop rated flow BAR	35
Pressure drop rated flow PSI	500
Pressure rating BAR	350
Pressure rating PSI	5000
Product height in	5.700
Product height mm	144.780
Product length in	11.000
Product length mm	279.400
Product width in	2.740
Product width mm	69.596
Seal type	Fluorocarbon
Special features	None
Spool Type	P port blocked, A, B, T connected
Stage	Single stage
Symmetric flow	Yes
Tank port rating BAR	250
Tank port rating PSI	3600
Valve Mount Type	Line
Valve type	AxisPro level 2
Working temp max C	70
Working temp max F	158
Working temp min C	-20
Working temp min F	-4

852AN00020B: frequently asked questions

When can 852AN00020B be shipped?

852AN00020B is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 852AN00020B in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 852AN00020B and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 852AN00020B, subject to availability and destination.
