HYDRAULIC PACKAGE SYSTEMCENTER
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | Standard hydraulic power units |
| Lifecycle | active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
Shipping & availability
When can 84013044 be shipped?
84013044 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 84013044 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 84013044 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 84013044, subject to availability and destination.
Danfoss HYDRAULIC PACKAGE SYSTEMCENTER, manufacturer part number 84013044. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.
Specifications
Specifications
| Accessory ready | (1) 1"NPT coupling w/downline |
| Accumulator with manual dump | Not required |
| Air bleed | Not required |
| Communication interface | Not required |
| Containment tray | Not required |
| Cooling | Air/oil RM casedrain(3GPM max) |
| Design | Low pressure(UP TO 3000PSI)sae |
| Directional valve coil voltage | 120VAC 60HZ / 110VAC 50HZ |
| Directional valve lights | Not required |
| Drive size | Not required |
| Filler/breather | Standard filler/breather |
| Filter | 60 GPM, 10um, spin-on return |
| Future expansions | TBD - future expansion |
| Low level/temp switch | Not required |
| Manifold w/rel or inline rel | 4-Station parallel manifold |
| Manifold/valve size | D05 |
| Motor | 10HP230/460/3/60+190/380/3/50 |
| Motor type | Gen. purpose VFD ready-700/300 |
| Motor variable frequency drive | Not required |
| Paint | Default-danfoss grey ral-7024 |
| Pressure gauge/sensor | 0-3000 PSI |
| Product Series | System center |
| Pump | 32.9 CC(2.01 CID) / Rev piston |
| Pump controls | Piston adj. displacement stop |
| Reservoir | 40 Gallon/151 liter |
| Station1 dir or prop valve | 3P/4W spring center-closed p |
| Station1 position1 stack valve | Dual P0 check - port A&B |
| Station1 position2 stack valve | Not Required |
| Station1 position3 stack valve | Not Required |
| Station2 dir or prop valve | Cover plate-all ports blocked |
| Station2 position1 stack valve | Not Required |
| Station2 position2 stack valve | Not Required |
| Station2 position3 stack valve | Not required |
| Station3 dir or prop valve | Cover plate-All ports blocked |
| Station3 position1 stack valve | Not Required |
| Station3 position2 stack valve | Not required |
| Station3 position3 stack valve | Not required |
| Station4 dir or prop valve | Cover plate-all ports blocked |
| Station4 position1 stack valve | Not required |
| Station4 position2 stack valve | Not required |
| Station4 position3 stack valve | Not required |
