Danfoss 84011955

SERVO PROPORTIONAL- SIZE 05, KBSD140500000096L80N11C07NSN01H0010000000

MPN: 84011955
Category: Industrial valves

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 84011955?

Danfoss SERVO PROPORTIONAL- SIZE 05, KBSD140500000096L80N11C07NSN01H0010000000, manufacturer part number 84011955. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Actuation	Solenoid operated single stage
Brand	Vickers by Danfoss
Coil Rating & Overrides	24 VDC Amplifier supply, water-resistant overrides
Command Signal	+/- 10V Voltage
Configuration level	Directional level - 1
Design Series	Design series -01
Digital Comm. Interface	Not selected
Electrical Connections	7 -PIN connector without plug, no enable
EN Series	Omit for standard
External Sensor	NONE
ISO Interface	ISO 4401 size-05
Model	Industrial proportional valves
Model Code 1	KBSD140500000096L80N11C07NSN01
Model Code 2	H0010000000
Monitor Output	±10V Voltage feedback signal
Pilot Supply & Drain Option	None_
Software Version	Software version -001
Spool Type	Symmetric -80LPM - at failsafe -A,B,T connected
Valve Type	Proportional valve with integrated amplifier and electronic feedback

84011955: frequently asked questions

When can 84011955 be shipped?

84011955 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 84011955 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 84011955 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 84011955, subject to availability and destination.
