Danfoss 83143768
GEAR PUMP GR2 FIXED DISPL COVER PORTS
- MPN
- 83143768
- Category
- GearMe single stage
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the Danfoss 83143768?
Danfoss GEAR PUMP GR2 FIXED DISPL COVER PORTS, manufacturer part number 83143768. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.
Specifications
Specifications
| Displacement | Displacement 22 cc |
| Drive gear | Splined SAE J498-11T-16/32-Dp Class 1FIT -SC06 SKP2 |
| Inlet size | Without inlet |
| Mark position | Position Marking standard (on the top in relation to drive gear) |
| Mark type | Standard Marking |
| Mounting flange | Flange SAE A, pilot Ø82,55 mm and 2 holes for bolts |
| O-Ring, Inside Diameter | Slash |
| Outlet size | Without inlet |
| Ports position | Standard from catalogue |
| Project version | Standard Version of Project |
| Proposition 65 | Cancer and Reproductive Harm |
| Rear cover | Cover for pump front SAE Thred ports : Inlet 1-1/16-12UN-2B ; Outlet 7/8-14UNF-2B |
| ROTATION | Product with clockwise rotation |
| Screws | Screws standard |
| Seals | Standard seal |
| Single Stage Family | Gr2 Hi.Torque Pump-Front port |
| Slash separator | Slash |
| Valve setting | without setting |
83143768: frequently asked questions
When can 83143768 be shipped?
83143768 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 83143768 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 83143768 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 83143768, subject to availability and destination.
