Danfoss 83115744

GEAR PUMP GR2 FIXED DISPL

MPN: 83115744
Category: GearMe single stage

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 83115744?

Danfoss GEAR PUMP GR2 FIXED DISPL, manufacturer part number 83115744. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Displacement	Displacement 11 cc
Drive gear	Splined SAE J498-9T-16/32-Dp Class 1FIT -SC06
Inlet size	20x40xM6
Mark position	Position Marking standard (on the top in relation to drive gear)
Mark type	Standard Marking
Mounting flange	Flange SAE A, pilot Ø82,55 mm and 2 holes for bolts
O-Ring, Inside Diameter	Slash
Outlet size	15x35xM6
Ports position	Port type Bx-Bx for flange SAE-A as per catalogue (inverted std. position from flange to cover) LCX
Project version	Standard Version of Project
Proposition 65	Cancer and Reproductive Harm
Rear cover	Standard cover for pump
ROTATION	Product with counter-clockwise rotation
Screws	Product with galvanized assembly screws ( +nuts, washers or cap nuts if listed on the Bill of Material )
Seals	Standard seal
Single Stage Family	Gr2 Pump
Slash separator	Slash
Valve setting	without setting

83115744: frequently asked questions

When can 83115744 be shipped?

83115744 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 83115744 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 83115744 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 83115744, subject to availability and destination.
