Danfoss 83107823

GEAR PUMP GR2 FIXED DISPL WITH VALVE

MPN: 83107823
Category: GearMe single stage

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 83107823?

Danfoss GEAR PUMP GR2 FIXED DISPL WITH VALVE, manufacturer part number 83107823. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Displacement	Displacement 25 cc
Drive gear	Taper 1:8 - M12 x 1,25 - Key = 4 CO01
Inlet size	1-1/16-12UN
Mark position	Position Marking standard (on the top in relation to drive gear)
Mark type	Standard Marking
Mounting flange	Flange with pilot Ø36,5 mm and 4 holes for bolts
O-Ring, Inside Diameter	Slash
Outlet size	7/8-14UNF
Ports position	Standard from catalogue
Project version	Standard Version of Project
Proposition 65	Cancer and Reproductive Harm
Rear cover	Cover for pump per relief valve
ROTATION	Product with clockwise rotation
Screws	Screws standard
Seals	Standard seal
Single Stage Family	Gr2 Pump+Int.drain RV
Slash separator	Slash
Valve setting	Setting relief valve, velocity of product per checked setting 2000 rpm and pressure 120 bar with oil ISO VG68 a 40°-50°C
