Danfoss 83096747

GEAR PUMP GR2 FIXED DISPL

MPN: 83096747
Category: GearMe single stage

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 83096747?

Danfoss GEAR PUMP GR2 FIXED DISPL, manufacturer part number 83096747. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Displacement	Displacement 11 cc
Drive gear	Splined SAE J498-11T-16/32-Dp Class 1FIT - ( rear tang 8 x 19,94 x L=6,5 ) (type 36)
Inlet size	20x40xM6
Mark position	Position Marking standard (on the top in relation to drive gear)
Mark type	Standard Marking
Mounting flange	Flange SAE A, pilot Ø82,55 mm and 2 holes for bolts
O-Ring, Inside Diameter	Slash
Outlet size	15x35xM6
Ports position	Port type Bx-Bx for flange SAE-A as per catalogue (inverted std. position from flange to cover) LCX
Project version	Standard Version of Project
Proposition 65	Cancer and Reproductive Harm
Rear cover	Not assigned (with intermediate flange instead cover)
ROTATION	Product with clockwise rotation
Screws	Screws standard
Seals	Standard seal
Single Stage Family	Gr2 Hi.Torque-Main stage
Slash separator	Slash
Valve setting	without setting
